Universal Turbocharger for all 1.5L-2.0L engine for all 4 cylinder Water + Oil cooling

Application

Universal for Turbo Manifold with T25 Flange(T28 Flange can be converted to T25 Flange, Adrapter is needed).

Perfect for all 1.5L-2.0L engine，for all 4 cylinder

Specification

Exhaust Inlet Flange: Standard T25 Flange

Exhaust Outlet  Flange: 5-Bolt

Turbine Side:

Turbine Trim: 76.3

Turbine A/R: 0.64

Turbine Inducer Diameter: 53.8mm

Turbine Exducer Diameter: 47mm

Compressor Side:

Compressor Trim: 48

Compressor A/R: 0.60

Compressor Inducer Diameter: 49.2mm

Compressor Exducer Diameter: 71 mm

Bearing Type: Wet Float

Cooling Type: Water + Oil Cooled

Wastegate: Internal Wastegate

Oil Restrictor: Yes

Oil Restrictor size：inside diameter 2mm

Oil Inlet: M12*1.25

Oil Outlet:M14 & 2*M8*1.25

Water: M14*1.5

Oil Drain Thread Pitch: 40mm

Water Thread Size: M14*1.5

Horse Power: Boost Horse Power up to 350BHP

Turbo Type: Individual

Condition: New

Accessories: You will get exactly as shown as picture above

package size：26x24x22cm

package weight：7250g

Warranty: one year warranty for any manufacturing defect

Feature

*Product Material

1. Turbine housing ：Ductile iron QT450-10 - temperature resistant up to 700℃

2. Steel turbine wheel：K418 alloy -  high  oxidation stability and resistance  up  to 900℃

3. Compressor housing：ZL104 aluminum with lightweight

4. Compressor wheel/blades：Cast aluminium blades – superior air tightness & corrosion resistance

*Product Performance

1. Cost-effective turbo increase 20-40% power for your car

2. Rich experience in turbo production and own factory

3. High-Speed oil seal ring and Precision clearance

4. Built for durability and strength

*Product Certification

TÜV ISO 9001 CERTIFIED

* Technology Advantage:

1. 100% balancing Test by TURBOTECHNICS  VSR3

2. G3-min-Flow VNT Turbo testing

3.  Advanced Actuator Tester/Programmer

Note

* Replace, repair or reconnect air cleaner element per manufacturer's manual to avoid compressor wheel damage.

* Make sure the oil drain line is lower than the turbo itself.

* Gasoline car must install a water cooling device to avoid overheating.

* Ensure exhaust outlet are well sealed by welding

* Professional installation is highly recommended

* This Turbo is not vehicle specific. Please check the specifications and verify compatibility prior to placing your order.

* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
